Forward FortiGate Firewall Logs to Arc for Long-Term Security Analytics

#Arc#Fortinet#FortiGate#firewall#syslog#Telegraf#security#logs#tutorial
Ignacio Van DroogenbroeckIgnacio Van Droogenbroeck
Cover image for Forward FortiGate Firewall Logs to Arc for Long-Term Security Analytics

If you're running FortiGate firewalls, you know the pain. FortiAnalyzer licenses aren't cheap, and cloud log retention gets expensive fast. But you need those logs—compliance, incident response, threat hunting. Deleting them isn't an option.

Here's the thing: FortiGate can forward logs via syslog to any server. Telegraf can receive syslog and push to Arc. Arc can store years of firewall logs and query them in seconds.

Let's set it up.

The Architecture

The flow is simple:

FortiGate → Syslog (UDP/TCP) → Telegraf → Arc → Grafana

FortiGate sends logs via syslog. Telegraf receives them, parses the fields, and forwards to Arc. You query with SQL and visualize in Grafana.

No FortiAnalyzer license required. No per-GB cloud costs. Just your own infrastructure.

Setting Up Telegraf

First, let's get Telegraf running with the syslog input plugin. Create a telegraf.conf:

# Telegraf configuration for FortiGate syslog

[agent]
  interval = "10s"
  flush_interval = "10s"
  hostname = ""
  omit_hostname = false

# Syslog input - listen for FortiGate logs
[[inputs.syslog]]
  server = "udp://:1514"
  best_effort = true
  syslog_standard = "RFC5424"

  ## For TCP with TLS (more reliable, encrypted)
  # server = "tcp://:6514"
  # tls_cert = "/etc/telegraf/cert.pem"
  # tls_key = "/etc/telegraf/key.pem"

# Output to Arc
[[outputs.influxdb_v2]]
  urls = ["http://arc:8000"]
  token = "$ARC_TOKEN"
  organization = "default"
  bucket = "firewall"

  [outputs.influxdb_v2.tagpass]
    # Only send syslog metrics
    measurement = ["syslog"]

A few notes:

  • Port 1514 is commonly used for syslog collection (avoids needing root for port 514)
  • best_effort = true extracts partial data from malformed messages—useful since not all FortiGate firmware versions output perfect RFC5424
  • UDP is simpler but TCP with TLS is more reliable for production

Docker Compose Setup

Here's a complete setup with Telegraf and Arc:

services:
  arc:
    image: ghcr.io/basekick-labs/arc:26.01.1
    container_name: arc
    restart: unless-stopped
    environment:
      - STORAGE_BACKEND=local
      - DB_PATH=/data/arc.db
    volumes:
      - arc-data:/data
    ports:
      - "8000:8000"

  telegraf:
    image: telegraf:1.33
    container_name: telegraf
    restart: unless-stopped
    environment:
      - ARC_TOKEN=${ARC_TOKEN}
    volumes:
      - ./telegraf.conf:/etc/telegraf/telegraf.conf:ro
    ports:
      - "1514:1514/udp"
    depends_on:
      - arc

  grafana:
    image: grafana/grafana:11.4.0
    container_name: grafana
    restart: unless-stopped
    environment:
      - GF_SECURITY_ADMIN_PASSWORD=admin
    volumes:
      - grafana-data:/var/lib/grafana
    ports:
      - "3000:3000"
    depends_on:
      - arc

volumes:
  arc-data:
  grafana-data:

Start it:

docker compose up -d

Get the Arc admin token from logs:

docker logs arc | grep "Admin token"

Set it as an environment variable and restart Telegraf:

export ARC_TOKEN=your-token-here
docker compose up -d telegraf

Configuring FortiGate

Now configure your FortiGate to send logs to Telegraf. You can do this via GUI or CLI.

Via GUI

  1. Log into FortiGate
  2. Go to Log & Report → Log Settings
  3. Enable Send Logs to Syslog
  4. Enter your Telegraf server IP and port (1514)
  5. Click Apply

Via CLI

SSH into your FortiGate and run:

config log syslogd setting
    set status enable
    set server 192.168.1.100
    set port 1514
    set mode udp
    set facility local7
    set format default
end

Replace 192.168.1.100 with your Telegraf server IP.

Enable Traffic Logging

By default, FortiGate might not log all traffic. To enable comprehensive logging:

config log syslogd filter
    set severity information
    set forward-traffic enable
    set local-traffic enable
    set multicast-traffic enable
    set anomaly enable
    set voip enable
end

Multiple Syslog Servers

FortiGate supports up to 4 syslog destinations. If you want redundancy or to send to multiple collectors:

config log syslogd2 setting
    set status enable
    set server 192.168.1.101
    set port 1514
end

Verifying the Flow

Once configured, you should see logs flowing into Arc. Check Telegraf logs first:

docker logs telegraf | tail -20

You should see messages about syslog input being initialized and metrics being written.

Query Arc to verify data is arriving:

curl -X POST http://localhost:8000/api/v1/query \
  -H "Authorization: Bearer $ARC_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{"sql": "SELECT * FROM syslog ORDER BY time DESC LIMIT 10", "database": "firewall"}'

Querying Firewall Logs

Now the fun part—analyzing your security data with SQL.

Recent Denied Traffic

SELECT
    time,
    appname,
    message
FROM syslog
WHERE message LIKE '%action=deny%'
ORDER BY time DESC
LIMIT 100

Top Source IPs by Volume

SELECT
    REGEXP_EXTRACT(message, 'srcip=([0-9.]+)', 1) as src_ip,
    COUNT(*) as event_count
FROM syslog
WHERE time > NOW() - INTERVAL '24 hours'
GROUP BY src_ip
ORDER BY event_count DESC
LIMIT 20

Failed VPN Logins

SELECT
    time,
    message
FROM syslog
WHERE message LIKE '%vpn%'
  AND message LIKE '%failed%'
ORDER BY time DESC
LIMIT 50

Traffic by Application

SELECT
    REGEXP_EXTRACT(message, 'app="([^"]+)"', 1) as application,
    COUNT(*) as hits,
    SUM(CAST(REGEXP_EXTRACT(message, 'sentbyte=([0-9]+)', 1) AS BIGINT)) as bytes_sent
FROM syslog
WHERE time > NOW() - INTERVAL '7 days'
GROUP BY application
ORDER BY hits DESC
LIMIT 20

Security Events Over Time

SELECT
    time_bucket(INTERVAL '1 hour', time) as hour,
    COUNT(*) as events,
    COUNT(CASE WHEN message LIKE '%action=deny%' THEN 1 END) as denied,
    COUNT(CASE WHEN message LIKE '%severity=critical%' THEN 1 END) as critical
FROM syslog
WHERE time > NOW() - INTERVAL '7 days'
GROUP BY hour
ORDER BY hour DESC

Grafana Dashboard

Connect Grafana to Arc using the DuckDB data source plugin, then create dashboards for:

  • Real-time event feed
  • Denied traffic by source IP
  • Bandwidth usage over time
  • VPN login attempts
  • Top blocked applications
  • Geographic distribution of traffic (if you parse srcip and do GeoIP lookups)

The queries above work directly in Grafana panels.

Storage Considerations

Firewall logs can be verbose. A busy FortiGate might generate gigabytes per day. Here's how to manage it:

Retention policy. Set up automatic deletion of old data:

curl -X POST http://localhost:8000/api/v1/retention \
  -H "Authorization: Bearer $ARC_TOKEN" \
  -H "Content-Type: application/json" \
  -d '{
    "database": "firewall",
    "measurement": "syslog",
    "retention_days": 90
  }'

Compression. Arc stores data in Parquet format with automatic compression. Expect 3-5x compression on log data.

Storage backend. For large deployments, use S3-compatible storage instead of local disk:

environment:
  - STORAGE_BACKEND=s3
  - S3_BUCKET=firewall-logs
  - S3_ENDPOINT=https://s3.amazonaws.com
  - AWS_ACCESS_KEY_ID=xxx
  - AWS_SECRET_ACCESS_KEY=xxx

TCP with TLS (Production)

For production, consider TCP with TLS instead of UDP:

Update Telegraf config:

[[inputs.syslog]]
  server = "tcp://:6514"
  tls_cert = "/etc/telegraf/server.crt"
  tls_key = "/etc/telegraf/server.key"
  tls_allowed_cacerts = ["/etc/telegraf/ca.crt"]

Update FortiGate:

config log syslogd setting
    set status enable
    set server 192.168.1.100
    set port 6514
    set mode reliable
    set enc-algorithm high
    set certificate "your-cert-name"
end

This ensures logs are encrypted in transit and delivered reliably.

Cost Comparison

Let's do the math. A mid-size FortiGate generating 10GB of logs per day:

FortiAnalyzer (on-prem):

  • License: ~$5,000-15,000/year depending on capacity
  • Hardware/VM costs
  • Maintenance

Cloud SIEM (per-GB pricing):

  • 10GB/day × 30 days × $2-5/GB = $600-1,500/month
  • That's $7,200-18,000/year

Arc (self-hosted):

  • Compute: ~$50-100/month for a decent VM
  • Storage: 10GB/day compressed to ~2GB × 365 = 730GB/year × $0.02/GB = ~$15/year on S3
  • Total: ~$600-1,200/year

You keep full control, query with standard SQL, and retain data as long as you want.

What's Next

This same pattern works for any device that speaks syslog:

  • Palo Alto firewalls
  • Cisco ASA/Firepower
  • pfSense/OPNsense
  • Linux servers (rsyslog/systemd-journald)
  • Network switches and routers

The key is Telegraf's syslog input plugin—it normalizes everything into a consistent format that Arc can query.

Resources

Questions? Drop by the Discord or reach out on Twitter.
